The Equations
|
Wing Sweep, C = |
(S * ((2 * B) + A)) / (3 * (A + B)) |
| MAC (length) = |
A - (2 * (A - B) * (0.5 * A + B) / (3 * (A + B))) |
| MAC location, d = |
Y * ((A - MAC) / (A - B)) |
| wing area, WA = |
2 * Y * ((A + B) / 2) |
| tail area, TA = |
2 * YY * ((AA + BB) / 2) |
| wing aspect ratio, ARw = |
(2 * Y) / ((A + B) / 2) |
| tail aspect ratio, ARt = |
(2 * YY) / ((AA + BB) / 2) |
| Tail Arm = |
(D - wing AC) + tail AC |
| tail volume, Vbar = |
(TA / WA ) * (Tarm / MAC) |
| NP (%MAC) = |
0.25 + (.7 * Vbar * (As / Aw) * ( 1 - de / da)); |
| ideal CG (%MAC) = |
NP - Desired Static Margin |
| actual CG (%MAC) = |
((Total Moment / Total Wt) - (Datum to LE + C)) / MAC |
| actual static margin % = |
(NP - actual CG) / MAC * 100 |
Center of Gravity (CG) is the point where the weight of the aircraft is balanced.
Neutral Point (NP) is the point where the aerodynamic forces of the wing and tail are balanced.
25% - 35% MAC is the typical range for the CG of a conventional aircraft .
Placing CG 5% to 15% of MAC in front of NP creates a longitudinal (pitch) stability
called Static Margin. A lower margin (tail heavy) produces less stability and greater elevator authority, while a
higher margin (nose heavy) creates more stability and less elevator authority. A static margin that's too high
may result in elevator stall at take off and landing.
Vbar is a unitless volume coefficient, based on the ratio of the wing surface area to the horizontal tail group (stabilizer and elevator)
surface area and the distance between the wing's AC and the tail's AC. It quantifies the tail's aerodynamic effectiveness and is used to calculate NP. Typical values range from
0.35 (smaller or closer to the wing, thus less effective) to 0.6 (larger or farther from the wing, thus more effective).
|
COPYRIGHT NOTICES:
- CG & MAC
equations adapted from the Public Domain.
- NP equations courtesy Alasdair Sutherland (see C.G.
Position article on Bloobird
Radio Flyers)
- Neutral Point and
Weight & Balance
Calculators developed by Dean A. Scott and are (c) 2005 -
, all rights reserved. Unauthorized use of the codebehind,
html, or content is strictly prohibitied.
Additional thanks to Geoff Haynes, vice-president, HMAC, for refinements to the code.
Email the author at dascott / at /
chrusion / dot / com to obtain copyright clearances to redistribute,
repurpose, and/or reuse all or parts of the code and content
herein.
|
|
